Account Manager support NIS
Allows online capacity expansion within the enclosure
Android/iOS mobile APP for monitoring
Backup to Cloud (Amazon S3)
Backup/Restore from attached storage (USB/eSATA/iSCSI/RDX/USM)
Backup/Restore from remote share (CIFS/NFS)
Bonjour Protocol, easily connect to NAS
Compression (Support on ZFS file system)
Central data and storage management
Data backup via backup plan/schedule
Data copy (1:1)
Deduplication (Support on ZFS file system)
EXT4 support extends over 16TB
iSCSI/share volume replication
ISO mount
Latest volume snapshot technology
Local and external account management, support large account import
Online expansion file system
Plug-in management
Select share or file for backup/restore
Share management and permission (support ACL setting)
Support Internet Gateway
Support iSCSI target for IP SAN
Support iSCSI initiator
Support iSCSI multi-host
Support e-mail notification, SNMP Trap/MIB, and system log
System configuration backup/restore
Thin Provisioning
Volume Clone (EXT3/EXT4/XFS/NTFS/VMFS/ZFS)
Volume replication to enhance data protection
VMware ESXi 5 iSCSI/NFS VAAI support
Wizard-oriented GUI design
WORM (Write Once Read Many) support CIFS/NFS
Overview
As the number of users and the amount of data grows, how to find a storage which can offer complete data protection, good performance, with reliability and high scalability is the key for all enterprises and companies. The NetServ_XS_12_Bay 6G SATA NAS based on latest proNAS 3.1 operating system. Except for basic NAS functions, it supports a variety of advanced storage management and application features such as VAAI, Thin- Provisioning, etc. It can be deployed easily in any IT environment since it supports multiple interfaces for different host server and clients.
For data protection, NetServ_XS_12_Bay supports RAID level 0, 1, 5, 6, 10 and 50 modes, and drives can be set hot spares, have automatically hot rebuilding and online capacity expansion within the enclosure. NetServ_XS_12_Bay has a fully-featured backup solution including manual or scheduled backup for file, folder, and shares, and it can be backup and restore from multiple local or remote devices. And there are volume clone, snapshot, remote replication, and data copy for options, which are all designed to ensure and enhance your precious data.
Technical Specifications
| NetServ XS 12 Bay |
| H/W Platform |
|---|
| Intel Pentium Dual Core 3.2GHz CPU or above |
| Cache memory : 8GB DDR3 up to 16GB |
| Four USB3.0 and Two USB2.0 ports |
| Two Gigabit Ethernet ports |
| Up to Twelve 2.5"/3.5” hot-swappable 6Gb/s SATA hard drives |
| Real-time drive activity and status indicators |
| Environmental monitoring unit |
| Two(2) 400W hot-swappable power supplies with PFC |
| RAID Controller Specifications |
| Highpoint RocketRAID 2720 |
| Support RAID level: RAID 0, 1, 5, 6, 10, 50 |
| Support drive hot spare and automatic hot rebuild |
| Allow online capacity expansion within the enclosure |
| Locally audible event notification alarm |
| Storage Management |
| Volume management (Support ZFS, XFS, EXT3 and EXT4 file system) |
| Support Compression and Deduplication (Support on ZFS file system) |
| Disk usage statistics |
| Hot spare drives |
| iSCSI Target manager: Support LUN Mapping/Initiator Filter/Thin Provisioning |
| VAAI support for iSCSI/NFS |
| General |
| Independent file server |
| Multiple language support |
| Support UPS |
| Support LV encryption |
| System Management |
| Automatic IP address configuration |
| Web browser-based management |
| SNMP management and notification |
| Fail-free online firmware upgrade |
| Unicode support |
| Multi-node management GUI |
| System configuration backup/restore |
| Central management |
| Quick wizard |
| APP for Android/iOS monitoring |
| Networking |
| Support NIC/Trunking/Load Balance/Fail Over/802.3ad |
| DHCP Server/DHCP Client |
| WINS Server |
| Internet gateway |
| DDNS |
| Protocols |
| TCP/IP, SMB/CIFS, NFS, SNMP, FTP/SFTP/FXP, HTTP, HTTPS, Telnet, SSH, AFP, WebDAV, Bonjour, TFTP |
| Client Operating Systems Support |
| Microsoft® Windows® 98/ME/NT/2000/XP/2003/Vista/2008/Win7/Windows 2012/Win 8 |
| Unix/Linux |
| Mac OS |
| Authentication |
| Local user account/group |
| Microsoft NT Domain Controller (PDC) |
| Microsoft Active Directory Authentication (ADS) |
| Network Information Service (NIS) |
| Support OpenLDAP service |
| Support creating users by batch |
| User quota management |
| Share level security |
| File level security |
| User ID security for NFS |
| Recycle bin (Samba) |
| File access log, audit (Samba) |
| Write Once Read Many (WORM) |
| Block Storage |
| iSCSI Target Support |
| Thin Provisioning support |
| VMware VAAI support |
| Virtualization |
| VMware/Citrix/Hyper-V |
| VMware VAAI for NFS support |
| Attached Storage |
| ISO Mount |
| USB/eSATA*/iSCSI initiator |
| Data Backup / Restore |
| Volume Clone (EXT3/EXT4/XFS/NTFS/VMFS/ZFS) |
| Symantec BackupExec Agent (by additional installation) |
| Scheduling multi-snapshot (Support iSCSI snapshot) |
| Replication (Remote realtime data mirroring) |
| Scheduling Rsync Replication |
| Support NetVault backup client (by additional installation) |
| Support CA ARCserve (by additional installation) |
| Data copy (copy files to other share/attached storage) |
| Scheduling backup |
| Differential/incremental backup |
| iSCSI Replication |
| Amazon S3 backup |
| backup/restore from attached storage |
| (USB/eSATA*/iSCSI/RDX*/USM*) |
| Support Apple Time Machine |
| Plug-in management |
| Anti-Virus |
| Central management |
| iTunes Server |
| Virtualization (VM on NAS) |
| Power requirements |
| AC 100V ~ 240V Full range
8A ~ 4A, 47~63Hz |
| Environmental |
| Relative Humidity: 10%~85% Non-condensing |
| Operating Temp: 10°C ~ 40°C (50°F ~ 104°F) |
| Physical Dimensions : 88(H) x 482(W) x 620(D)mm |
Specification are subject to change without notice. All company and product names are trademarks of their respective owners.
